| Model | Heating Power(kw) | Blower (kw) | Tank Capacity (L) | Dimensions (mm) | Floor Stand Size (mm) | Whole Height (mm) | Air Outlet Pipe Diameter | Air Inlet Pipe Diameter | Diameter of Suction Box | Approx. Net Weight (kg) |
| XCD-80U | 4 | 0.135 | 80 | 933*730*500 | 864*732*550 | 1510 | 2\" | 2\" | Φ38 | 80 |
| XCD-120U | 4.5 | 0.21 | 120 | 1175*730*505 | 865*735*550 | 1750 | 2.5\" | 2.5\" | 90 | |
| XCD-160U | 6 | 0.215 | 160 | 1195*810*610 | 865*800*670 | 1725 | 2.5\" | 2.5\" | 110 | |
| XCD-230U | 9 | 0.32 | 230 | 1495*865*610 | 865*800*670 | 2010 | 3\" | 3\" | 110 | |
| XCD-300U | 12 | 0.32 | 200 | 1490*980*730 | 1015*950*790 | 2080 | 3\" | 3\" | Φ51 | 110 |
| XCD-450U | 15 | 0.32 | 450 | 1840*1005*725 | 1015*950*790 | 2430 | 3\" | 3\" | 130 | |
| XCD-600U | 18 | 0.5 | 600 | 1815*1215*920 | 1145*1200*1000 | 2425 | 4\" | 4\" | 200 | |
| XCD-750U | 18 | 1.5 | 750 | 1975*1255*920 | 1145*1200*1000 | 2575 | 4\" | 4\" | 220 | |
| XCD-900U | 18 | 1.5 | 900 | 2085*1345*1010 | 1145*1200*1000 | 2600 | 4\" | 4\" | 250 | |
| XCD-1200U | 30 | 1.5 | 1200 | 2540*1450*1050 | 1040*1270*1220 | 3140 | 4\" | 4\" | Φ51 | 450 |
| XCD-1500U | 32 | 2.2 | 1500 | 1890*1450*1050 | ... | 3490 | 5\" | 5\" | 500 | |
| XCD-2300U | 38 | 3.7 | 2300 | 3030*1650*1250 | ... | 3630 | 6\" | 6\" | Φ63 | 650 |
| XCD-3000U | 48 | 3.7 | 3000 | 3630*1660*1300 | ... | 4230 | 6\" | 6\" | 740 | |
| XCD-4500U | 80 | 5.5 | 4500 | 5180*2670*1630 | ... | 5180 | 8\" | 8\" | 940 | |
| XCD-6000U | 96 | 7.5 | 6000 | 5700*2900*1850 | ... | 5700 | 8\" | 8\" | 1210 | |
| XCD-7500U | 120 | 11 | 7500 | 4955*2325*1875 | ... | 5555 | 8\" | 8\" | 2100 |
